Type: LED screen dedicated for indoor installation demanding image in high resolution
Application: TV studios, traffic/crisis control centres, video conferences, stock exchanges, high resolution advertising banners
Distinguishing feature: Image in HD resolution 2k,4k,8k
| Pixel pitch: | 3.13 mm (0.12in) | 3.57 mm (0.14in) | 3.91 mm (0.15in) |
| Pixel Density (pixels/m2) | 102,400 | 78,400 | 65,410 |
| Pixel Configuration | SMD 2020 | SMD 2020 | SMD 2020 |
| Module Dimension | 250*250mm 9.84*9.84in |
250*250mm 9.84*9.84in |
250*250mm 9.84*9.84in |
| Module Resolution (pixels) | 80*80 | 70*70 | 64*64 |
| Cabinet Dimensions (W*H*D) | 500*500*80mm 19.69*19.69*3.15in |
500*500*80mm 19.69*19.69*3.15in |
500*500*80mm 19.69*19.69*3.15in |
| Cabinet Resolution (pixels) | 160*160 | 140*140 | 128*128 |
| Weight (kg/cabinet) | 7.35kg (16.2lb) | 7.35kg (16.2lb) | 7.35kg (16.2lb) |
| Material | Aluminium | Aluminium | Aluminium |
| Brightness (nits) | adjustable | adjustable | adjustable |
| Brightness sensor (optional) | Yes | Yes | Yes |
| Viewing angle | >=178o/178o | >=178o/178o | >=178o/178o |
| Best viewing distance (m) | 4~11 | 4.5~12 | 5~13 |
| Display color | 281 trillions | 281 trillions | 281 trillions |
| Gray Scale levels (bits) | 16 | 16 | 16 |
| Max Power consumption (W/m2 ) | 500 | 650 | 650 |
| Input voltage | 100~ 240V, 50/60Hz | ||
| Refresh rate (Hz) | >2000 | >2000 | >2000 |
| Color Temperature | 1000~11000 | 1000~11000 | 1000~11000 |
| Input signal | VGA, DVI, HDMI etc. | VGA, DVI, HDMI etc. | VGA, DVI, HDMI etc. |
| Controlling system | Colorlight | Colorlight | Colorlight |
| Humidity range | 10%~60% | 10%~60% | 10%~60% |
| Temperature Range | -10 ~45 | -10 ~45 | -10 ~45 |
| Protection rating | Front IP20; Rear IP41 | Front IP20; Rear IP41 | Front IP20; Rear IP41 |
| LED lifetime (hours) | 100,000 | 100,000 | 100,000 |
Parameters can be modified according to the individual order.
