No flicker on Camera
16-bit image processing, 281 trillions of colors
High-end components
On-site maintenance in Europe
Management system compliant with ISO 9001 and ISO 14001
Electromagnetic compatibility (EMC)
High brightness
Portable construction
Light weight
Heat dissipation
High refresh
Wide viewing angle
Low power consumption
Front serviceable, easy access
High accuracy of installation, diecast system
Seamless display
Ultrathin module
Fast installation
Back serwis
HD Image
Black face SMD

Type: LED screens dedicated for outdoor portable and fixed installation, i.e information boards, advsertising banners

Application: Conference, congress and symposium events, exhibitions fairs, concert scenes, store windows

Distinguishing feature: Fast in assembling and dismantling, easy in transportation

Ask about this product

Tech Specs


Pixel pitch: 6.25 mm(0.25in) 6.94 mm(0.27in) 8.33 mm(0.33in)
Pixel Density (pixels/m2) 25,600 20,735 14,411
Pixel Configuration SMD 3 in 1 SMD 3 in 1 SMD 3 in 1
Module Dimension 250*250mm(9.84*9.84in) 250*250mm(9.84*9.84in) 250*250mm(9.84*9.84in)
Module Resolution (pixels) 40*40 36*36 30*30
Cabinet Dimensions 500*500mm*90mm
Cabinet Resolution (pixels) 80*80 72*72 60*60
Brightness (nits) 5,500 5,000 5,000
Weight (kg) 8.3kg(18.3lb) 8.5kg(18.8lb) 8.5kg(18.8lb)
Max Power consumption (W/m2) 620 600 630
Best viewing distance (m) 8~20 9~23 10~27
Viewing angle Horizontal: 140o, Vertical: 140o
Gray Scale levels (bits) 16 16 16
Refresh rate (Hz) >1,500 >1,500 >1,500
Protection rating Front IP65; Rear IP54 Front IP65; Rear IP54 Front IP65; Rear IP54
LED lifetime (hours) 100,000 100,000 100,000
Input voltage 90~ 260VAC, 50/60Hz
Humidity range 10%~99% 10%~99% 10%~99%
Temperature Range -20 ~60 -20 ~60 -20 ~60

Parameters can be modified according to the individual order.
