Type: LED screens dedicated for outdoor portable and fixed installation, i.e information boards, advsertising banners, telebims, video walls
Application: Conference, congress and symposium events, exhibitions fairs, concert scenes, store windows
Distinguishing feature: Fast in assembling and dismantling, easy in transportation
| Pixel pitch: | 10 mm(0.39in) | 16 mm(0.63in) |
| Pixel Density (pixels/m2) | 10,000 | 3,906 |
| Pixel Configuration | 1R1G1B | 1R1G1B |
| Module Dimension | 160*160mm(6.30*6.30in) | 256*128mm(10.08*5.04in) |
| Module Resolution (pixels) | 16*16 | 16*8 |
| Cabinet Dimensions | 640*640mm(25.20*25.20in) | 768*768mm(30.23*30.23in) |
| Cabinet Resolution (pixels) | 64*64 | 48*48 |
| Brightness (nits) | 5,800 | 7,500 |
| Max Power consumption (W/m2) | 700 | 800 |
| Best viewing distance (m) | 10~27 | 20~53 |
| Viewing angle | Horizontal: 120o, Vertical: 60o | |
| Gray Scale levels (bits) | 16 | 16 |
| Refresh rate (Hz) | >1,000 | >1,200 |
| Protection rating | Front IP65; Rear IP54 | Front IP65; Rear IP54 |
| LED lifetime (hours) | 100,000 | 100,000 |
| Input voltage | 90~ 260VAC, 50/60Hz | |
| Humidity range | 10%~99% | 10%~99% |
| Temperature Range | -20 ~60 | -20 ~60 |
Parameters can be modified according to the individual order.
